Application:
1. Commercial lighting: high-class stores, shopping malls, hotels, restaurants, airport and so on.
2. Office lighting: Conference/Meeting rooms, Factories, offices and so on.
3. Institution Buildings: Schools, colleges, universities, hospitals, pharmacy and so on.
Features:
1. Ultra-thin, the thickness is 9 mm, edge-lighting
2. Heat dissipation: Aluminum PCB which ensure heat dissipation in time as well as warranty long life-span of the light.
3. Light efficiency: 60-70 Lm/w.
4. No pollution, No UV radiation, no RF interference, no flickering.
5. Easy installation: Recessed, suspended, surface mounted.
6. Long life span 50, 000 hours.
7. Warranty: 3 years
Product parameters:
Item | AT-SPL-S0303S2-018FW/N/C |
Product No.: | AT-SAL-S0303S2-018FW | AT-SAL-S0303S2-018FN | AT-SAL-S0303S2-018FC |
Brand: | AOTO |
Dimension： | 298*298*9mm |
Input Voltage: | AC110-240V / 50-60Hz |
Wattage: | 18W |
Color temperature: | WW (2700-3500k) | NW (4000-4500k) | CW( 6000-6500k) |
Luminous: | ≥1260Lm | ≥ 1310Lm | ≥1350Lm |
Luminous efficiency | ≥72 Lm/w | ≥ 74 Lm/w | ≥ 74 Lm/w |
Ra | ＞73 | ＞73 | ＞73 |
Power Factor | ≥0.9 |
Beam Angle | 120° |
IP | IP20 |
Operation Temperature | -20°C ~ +45°C |
Storage Temperature | -25°C ~ +55°C |
Net weight | 0.9KG |
Gross weight | 1.4KG |
